Totem is a multimode voltage controlled filter with 16 different filter modes based on the 3109 OTA chip used in classic synths like the Roland SH-101, MC-202, Jupiter-8 and others.
Features:
- Massive drive control for endless tone variety
- CV control via attenuator
- CV control via attenuverter
- V/OCT control with half and negative half scaling
Filter Modes:
| Mode | A | B |
| 1 | 24dB LPF | 18dB LPF |
| 2 | 12dB LPF | 6dB LPF |
| 3 | 12dB HPF + 6dB LPF A | 12dB HPF |
| 4 | 18dB HPF + 6dB LPF | 18dB HPF |
| 5 | 24dB BPF | 12dB HPF + 6dB LPF B |
| 6 | 12dB BPF | 6dB HPF |
| 7 | 12dB Notch + 6dB LPF | 12dB Notch |
| 8 | 18dB Allpass (phase) + 6dB LPF | 18dB Allpass (phase) |
Specifications
• Width: 12HP
• Depth: 25 mm
• Current Draw: +12 V: 20mA, -12 V: 10 mA
